Nanasaheb Mahadik Polytechnic Institute Today:
Department - Civil Engineering
Year of Establishment: 2011 Total Intake: 60
The Civil Engineering programme is started at ‘Nanasaheb Mahadik Polytechnic Institute’ from 2011 with an intake capacity of 60 students. As institute is taking hard efforts for the complete development, the department of Civil Engineering is boosting its speed of development and that is proved when M.S.B.T.E. sanctioned extra intake 60 seats. Thus total intake of Civil Engineering is now 120 seats. This is most valuable achievement for the institute. Also this shows that Civil Engineering is successfully maintained its position in Science and Technology stream from the ancient time to up till now.

Civil Engineering is the primary branch for human being as it deals with living and non-living organism directly-indirectly. The basic needs of human being are food, garments and shelter out of that food and shelter are basically fulfilled by only Civil Engineering from long time. This branch of engineering contains very huge area science and its sub branches. This stream of engineering deals with subjects like physics, chemistry, mathematics, applied science, structural engineering, surveying, geology, soil mechanics, transportation engineering, town planning engineering, water resource engineering, hydrology, concrete technology, etc. are most important fields and parts in Civil Engineering. The seven wonders of the world are nothing but creativity and perfect application of Civil Engineering. It proves that Civil Engineering is very old branch in technology area runs from Vedic time.

Department of Civil Engineering
Year of Establishment 2011
Head of Department Mr. Yogesh A. Patil
Contact - Ph. No. 9422203222
Email office.nmpi@gmail.com
Total number of Laboratories 12
Teaching Faculty 06
Supporting Staff 02
Total number of Classrooms 02
Total Intake 60
Total Area 1086 Sq.mtr.

Civil Engineering Laboratories:
1. Engineering Mechanics Lab
Name of Laboratory : Engineering Mechanics Lab
Area of Laboratory : 85.00 SQ. M.
Laboratory Resources: Universal Force Table
Parallel Force Apparatus
Compound Wheel & Axle
Double Purchase Winch Crab
Worm & Worm Wheel - a) Single Start b) Double Start c) Triple Start
Weston’s Differential Pulley Block
Double Sheave Pulley Block
Simple Screw Jack
Friction Apparatus
Law of Moment Apparatus
Differential Pulley Block
Simple Jib Crane
Utilization of Laboratory: Civil Engineering, Mechanical Engineering, Electrical Engineering,

2. Strength of Material Lab
Name of Laboratory : Strength Of Material Lab
Area of Laboratory : 85.00 SQ. M.
Laboratory Resources: Universal Testing Machine
Brinell Hardness Machine
Rockwell Hardness Machine
Torsion Testing Machine
Impact Testing Machine
Extensometer
Utilization of Laboratory: Civil Engineering, Mechanical Engineering

    3. Concrete Technology Lab
Name of Laboratory : Concrete Technology Lab
Area of Laboratory : 75.31 SQ. M.
Laboratory Resources: IS Sieves
Compression Testing Machine
Vee Bee Apparatus
Slump  Cone Apparatus
IS Cubes
Utilization of Laboratory: Civil Engineering

    4. Geotechnical Engineering Lab
Name of Laboratory : Geotechnical Engineering Lab
Area of Laboratory : 75.31 SQ. M.
Laboratory Resources: Tri-axial Test Apparatus
Direct Shear Test Setup
Consolidation Test Apparatus
Unconfined Compression Test Apparatus
 Permeability Test Setup
Liquid  Limit  Device
Utilization of Laboratory: Civil Engineering

5.Surveying Lab
Name of Laboratory : Surveying Lab
Area of Laboratory : 75.31 SQ. M.
Laboratory Resources: Total Station
Auto Level
Dumpy Level
Tilting Level
Hand Level
Digital Planimeter
Theodolite
Utilization of Laboratory: Civil Engineering

    6. Fluid Mechanics Lab
Name of Laboratory : Fluid Mechanics Lab
Area of Laboratory : 75.00 SQ. M.
Laboratory Resources:
  • Bernoulli’s Apparatus
  • Heleshaws Apparatus
  • Venturimeter Apparatus
  • Orifice Apparatus
  • Pipe friction Apparatus
  • Reynolds Apparatus
  • Pelton wheel Turbine
  • Francies Turbine
Utilization of Laboratory: Civil Engineering

    7. Public Health Engineering Lab
Name of Laboratory : Public Health Engineering Lab
Area of Laboratory : 75.31 SQ. M.
Laboratory Resources:
  • Bernoulli’s Apparatus
  • Heleshaws Apparatus
  • Venturimeter Apparatus
  • Orifice Apparatus
  • Pipe friction Apparatus
  • Reynolds Apparatus
  • Pelton wheel Turbine
  • Francies Turbine
Utilization of Laboratory: Civil Engineering

8. AUTO-CAD Lab
Name of Laboratory : Auto-Cad  Lab
Area of Laboratory : 60.61 SQ. M.
Laboratory Resources: Hardware:
Intel Pentium 2.6 GHz, 2 GB DDR3 RAM, 500 GB HDD SATA,
LED HP Monitor (W1972a), Multimedia Keyboard and Mouse (25 nos.)
D-Link 8 & 16 Port Switch, Epson Printer.
Software’s:
AutoCAD
Microsoft Office
Utilization of Laboratory: Civil Engineering
